DLS Performence CA41 - 4 X 70W





Pieces:











CA 41 is a powerful amplifier with power output of 4 x 70 Watts. With a mono bridge-connection, it puts out all of 200 Watts.



- Built-in/switchable low-pass and high-pass filters.

- Bass boost 25 Hz - 80 Hz 0-18 dB.

- Built-in protection circuits shut down the amplifier in the event of overloads. Use it for a front system and a subwoofer. High level input with auto start.

- RMS output power @ 13,8 V, 20Hz - 20 kHz



Specifications:

Number of channels : 4

Amplifier class : AB

Output power in 4 ohm : 4 x 70 W

Output power in 2 ohm : 4 x 125 W

Mono bridge mode 4 ohm : 2 x 200 W

Damping factor : >100

S/N ratio, A-weighted : > 100 dB

Frequency range : 10 Hz - 35 kHz

Input sensitivity : 0,25 - 5 V

Input impedance : >10 kohm

Input impedance, high level : 100 ohm

Filters channel A & B : HP: 15-500 Hz. LP: 50-500 Hz / 0,5 - 5 kHz (x10)

Filters channel C & D : HP: 15-500 Hz / 150 Hz - 5 kHz (x10)

Grand bass filter : 0-18 dB @ 25-80 Hz

Low level output : Yes

High level input with auto start : Yes

Power consumption (idle) : 0,7 A

Power consumption (max) : 60 A

Rec. power cable Minimum : 4AWG / 21 mm2

Fuses : 2 x 30 A

Dimension (W x D x H) : 70 x 372 mm x 268 mm (2,92 x 14,65 x 10,55 inches)

Weight : 4,2 kg ( 9,3 lb)

Price : Rp. 3.150.000

For The Link:

DLS Performence CA41



For more information about this product available @ Cliport Car Audio
