JUAL Jual 4 X 100 Watt 4 Ohm Class D Audio Amplifier Board - TK2050 4CH 100W Power T-Amp

Hilarious

Kondisi Barang : New

Harga :

Lokasi Seller : Jawa Barat

Description :

Agan-Agan ceriwisser,

Numpang jualan digital amplifer board 4 channel Tripath 4 x 100 W, cocok buat bikin amplier mobil berkualitas tinggi , very low distortion dan tidak panas

Feature:

� A perfect " Class D" archiitecture

� Frequency response:20Hz to 20KHz(�3dB)

� Single end audio signal input

� Over/under voltage protection

� Over current protection

� Over temperature protection

Specifications:

Parameter Condition Min. Typ. Max.

Supply Voltage - 10V 27V 30V

Input Sensitivity Pout=100w - 520mV -

Quiescent Power (W) Vmute=0V

VCC=30V - 12.6 -

Standby Power (W) Vmute=5V

VCC=30V 6.6

Efficiency Pout=100W - 90.3% -

Input Impedance - - 10K ohm -

Load - 3.2 ohm 4 ohm -

Gain?dB? 32

Operating Temperature - 0? 20? 70?

Storage Temperature - -20? 20? 105?

Thermal Shutdown - - 150? -

Applications:

It is the ideal solution for any sound reinforcement installation or application needing an affordable compact PA system.

� Background Music Systems

� Vending machines

� Lifts

� Interactive kiosks

� Home DIY

� Car audio

Benefits:

� Mounting holes facilitate installation and fixing

� Several wiring methods facilitate connection?RCA Socket (Default),Terminal Block(Optional)

� Excellent design of the power ports which allows you to connect multiple amplifier boards in series (Terminal Block Optional)

� Excellent heat dissipation eliminates the requirement of an extra heat sink

Harga : Rp 550.000

Bila berminat bisa menghubingi :

Lokasi Depok,

Thanks,

Salam,

Lukman B

0812-805-69-444 atau [email protected] atau pin BB 28428C1D
