Honda Civic Wonder SB3 Club
Honda Civic Wonder SB3 Club
( Civic 3rd Gen SB3 1984 - 1987)
Code:
http://www.sb3club.com/
Code:
CivicWonder-SB3-Club : Civic Wonder SB3 CLUB
Code:
http://www.facebook.com/group.php?gid=311497623741
BB Groups CivicWonderSB3-Club - Scan Group Barcode
[/spoiler]
Spoiler for open this:
for Civic Wonder SB3:

[/quote]
Quote:
Originally Posted by checkman
biar tambah ngebul...
Civic SB3 (3 Door Hatchback) Indonesian Market
- Length x Width x Height: 3.810 m x 1.630 m x 1.340 m
- Wheel Base: 2.380 meter
- Ground Clearance: 0.15 meter
- Curb Weight: 835 kg
- Engine Type: EV Inline 4 SOHC
- Displacement: 1.342 cc
- Compression Ratio: 8.7:1
- Fuel System: Carburetor
- Max HP: 71 hp @6000 rpm
- Max Torque: 105 Nm @3500 rpm
- Fuel Tank Capacity: 45 liter
- Minimum Turning Radius: 4.5 meter
- Gear Ratio:
1st Gear: 3.272
2nd Gear: 1.666
3rd Gear: 1.041
4th Gear: 0.777
5th Gear: 0.655
Reverse Gear: 2.916
Final Gear: 4.066
Civic 23 SB3 JDM
- Curb Weight: 760 kg
- Engine Type: EV Inline 4 SOHC
- Displacement: 1.342 cc
- Bore x Stroke: 74.0�78.0
- Compression Ratio: 10.0
- Fuel System: Carburetor
- Max HP: 80 hp @6.000 rpm
- Max Torque: 111 Nm @3.500 rpm
Civic 25 SB3 JDM
- Curb Weight: 800 kg
- Engine Type: EW Inline 4 SOHC
- Displacement: 1.488 cc
- Bore x Stroke: 74.0�86.5
- Compression Ratio: 9.2
- Fuel System: Carburetor
- Max HP: 90 hp @6.000 rpm
- Max Torque: 126 Nm @3.500 rpm
Civic 25-i SB3 JDM
- Curb Weight: 815 kg
- Engine Type: EW Inline 4 SOHC
- Displacement: 1.488 cc
- Bore x Stroke: 74.0�86.5.0
- Compression Ratio: 8.7
- Fuel System: Honda PGM-FI
- Max HP: 100 hp @6.000 rpm
- Max Torque: 129 Nm @3.500 rpm
Civic Si SB3 JDM
- Curb Weight: 890 kg
- Engine Type: ZC Inline 4 DOHC
- Displacement: 1.590 cc
- Bore x Stroke: 75.0�90.0
- Compression Ratio: 9.3
- Fuel System: Honda PGM-FI
- Max HP: 135 hp @6.500 rpm
- Max Torque: 152 Nm @5.000 rpm
HTML Code:
Honda??????????? Honda???????
====================
Info Bengkel & Toko Spareparts
Bengkel Honda:
- Imora Motor (Honda Jakarta Center), Jl. Pangeran Jayakarta No.50, Jakarta Pusat 629 2846
- Honda Clinic, Jl. Pualam V, Sumur Batu, Jakarta Pusat, CP: Pak Andi, 021 91300470
- Lestari Motor, Jl. R.S. Veteran Raya No.9, Bintaro, Jakarta Selatan, CP: Ruddy, 021 738 81481
- Muhtar Motor, 021 83792058
Toko Spareparts:
- Karya Agung, Muzatek Building, Sawah Besar No. A-14, Jakarta Pusat, CP: Koh Teki 381 4040
- Niu Budi Motor, Jl. Sukarjo Wiryopranoto (Sawah Besar) No.69 C, Jakarta Pusat, CP: Koh Anci, 0852 170 101 99
- Jaya Makmur Motor, Pasar Mobil Kemayoran Blok C 12, Jakarta Pusat, CP: Koh Amin, 0818 881 769
- Sinar Jaya Motor, Pasar Cipete Lt Dasar Blok D No.5, Jl. R.S. Fatmawati, Jakarta Selatan, CP: Koh Ayen, 724 5635
- Parts Honda Ex-Singapore, Jl. Songsi, Jembatan 5, CP: Koh Akie
================
Oli Mesin:
- SAE 20W-50 Prima XP Mineral Rp.90.000,- / galon (4 liter)
- SAE 20W-50 Fastron Semi Synthetic Rp.39.000,- / liter
- SAE 15W-50 Shell HX5 Semi Synthetic
- SAE 15W-50 Total Quartz 5000 Semi Synthetic
- SAE 10W-50 Idemitsu Extreme Pro Full Synt Rp.285.000,- / galon (4 liter)
Oli Transmisi:
- Honda MTF
-
Minyak Rem:
- Honda Brake Fluid DOT 3
Busi:
- NGK, BP5EY
Aki:
-
Filter Oli:
- KW1 Rp.25.000,-
- Ori Rp.35.000,-
Filter Udara:
- Ori Rp.45.000,-
Harga-harga Body Parts:
- Wiper 18"
- Bumper Depan Rp.1.300.000-an
- Bumper Belakang Rp.1.300.000-an
- Lips
|
Quote:
[spoiler=open this] Depan Rp.700.000-an
- Mika Sein Bumper @Rp.90.000,-
- Mika & Housing Sein Bumper @Rp.150.000,-
- Sein & Lampu Senja @Rp.300.000,-
- Lampu Depan @Rp.500.000,-
- Lampu Belakang @Rp.500.000,-
- Bohlam Headlamp Stanley 4107 @Rp.50.000
(bisa disubstitusi dengan Bohlam dudukan H4 dengan menekuk kaki nya biar masuk  )
|
[quote]
|
