CPU

Intel Socket 775 Core 2 Quad/Core 2 Extreme/Core 2 Duo/Pentium D/Pentium 4/Celeron E1000 Series and Celeron 400 Series Processors, Intel� Hyper-Threading Technology ready, *Refer to www.asus.com for Intel CPU support list

Chipset

Intel G31

Intel ICH7

Front Side Bus

1600*/1333/1066/800 MHz (*1600 is overclock speed)

Memory

2 x DIMM, Max. 4 GB, DDR2 1066*/800/667 Non-ECC,Un-buffered Memory

Dual Channel memory architecture

*Overclock speed

**Refer to www.asus.com or user manual for Memory QVL (Qualify Vendor List)

***When installing total memory of 4GB capacity or more, WindowsR 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.

Expansion Slots

1 x PCIe x16

1 x PCIe x1

2 x PCI

VGA

Integrated Intel Graphics Media Accelerator (Intel� GMA 3100)

Max. resolution:2048x1536X32bpp, Horizontal:127.5KHz Vertical:85Hz

Storage

Southbridge

1 xUltraDMA 100/66/33

4 xSATA 3 Gb/s ports

LAN

Realtek RTL8102EL 100/10 LAN

Audio

VIA VT1708B 8 -Channel High-Definition Audio CODEC

Anti-Pop Function

Jack-detect & Multi-Streaming

Support S/PDIF Out connector

USB

8 USB 2.0 ports (4 ports at mid-board, 4 ports at back panel)

Back Panel I/O Ports

1 x Parallel

1 x VGA

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x LAN(RJ45) port

4 x USB 2.0/1.1

1 x COM port

8 -Channel Audio I/O

Internal I/O Connectors

2 x USB connectors support additional 4 USB ports

1 x CPU Fan connector

1 x Chassis Fan connector

1 x Power Fan connector

1 x internal speaker connector

1 x S/PDIF Out connector

1 x4-pin ATX 12V Power connector

24-pin EPS 12V Power connector

CD audio in connector

Front panel audio connector

Chassis Intrusion connector

CD/AUX audio in

System Panel

BIOS

8 Mb Flash ROM

DMI 2.0

AMI BIOS

PnP

WfM 2.0

SM BIOS 2.5

ACPI 2.0

Manageability

WOL,PXE,RPL,WOR ,PME Wake Up
